| Quantity: | |
|---|---|
LG-50
Kai en
Product Description
The dry screw vacuum pump is a rotor that uses a pair of parallel screws to make synchronous, high-speed and reverse rotation in the pump housing. The rotor and the inner wall of the pump body form a number of sealing spaces. During the rotation, the continuous transmission of gas is formed to achieve the purpose of suction and exhaust.
Technical parameter
| Type (Air cooled series) | Basic parameters | ||||||||
| Pumping speed (m3/h) | Presure limit(Pa) | Power (kW) | revolution (rpm) | Inlet caliber (mm) | outlet caliber (mm) | Pump head weight (kg) | noise dB(A) | Overall dimension (length*width*height) (mm) | |
| LG-10 | 10 | ≤5 | 0.75 | 2730 | KF16 | KF16 | 30 | ≤ 72 | 655x260x285 |
| LG-20 | 20 | ≤5 | 1.1 | 2840 | KF25 | KF25 | 55 | ≤72 | 720x305x370 |
| LG-50 | 50 | ≤10 | 2.2 | 2850 | KF40 | KF40 | 90 | ≤75 | 920x350x420 |
| LG-70 | 70 | ≤30 | 3 | 2850 | KF40 | KF40 | 110 | ≤75 | 910x390x460 |
| LG-90 | 90 | ≤30 | 4 | 2870 | KF50 | KF50 | 125 | ≤80 | 1000x410x495 |
Water cooling Dry screw vacuum pump
Application Area
Can extract condensable gases containing a large amount of water vapor and a small amount of dust, and can also be used to extract corrosive gases, oil and gas, solvents, and other media for recovery.
Factory Shooting
Workshop shooting, complete equipment, and rich production experience
Product Description
The dry screw vacuum pump is a rotor that uses a pair of parallel screws to make synchronous, high-speed and reverse rotation in the pump housing. The rotor and the inner wall of the pump body form a number of sealing spaces. During the rotation, the continuous transmission of gas is formed to achieve the purpose of suction and exhaust.
Technical parameter
| Type (Air cooled series) | Basic parameters | ||||||||
| Pumping speed (m3/h) | Presure limit(Pa) | Power (kW) | revolution (rpm) | Inlet caliber (mm) | outlet caliber (mm) | Pump head weight (kg) | noise dB(A) | Overall dimension (length*width*height) (mm) | |
| LG-10 | 10 | ≤5 | 0.75 | 2730 | KF16 | KF16 | 30 | ≤ 72 | 655x260x285 |
| LG-20 | 20 | ≤5 | 1.1 | 2840 | KF25 | KF25 | 55 | ≤72 | 720x305x370 |
| LG-50 | 50 | ≤10 | 2.2 | 2850 | KF40 | KF40 | 90 | ≤75 | 920x350x420 |
| LG-70 | 70 | ≤30 | 3 | 2850 | KF40 | KF40 | 110 | ≤75 | 910x390x460 |
| LG-90 | 90 | ≤30 | 4 | 2870 | KF50 | KF50 | 125 | ≤80 | 1000x410x495 |
Water cooling Dry screw vacuum pump
Application Area
Can extract condensable gases containing a large amount of water vapor and a small amount of dust, and can also be used to extract corrosive gases, oil and gas, solvents, and other media for recovery.
Factory Shooting
Workshop shooting, complete equipment, and rich production experience
