Product Description：
The 2BW water ring vacuum pump closed-loop unit is a vacuum pump unit composed of auxiliary components such as vapor liquid separator, heat exchanger, valve, instrument, and pipeline added to the water ring pump. This unit can allow the working fluid of the water ring vacuum pump to be continuously circulated in the gas-liquid separator and pump chamber, reducing sewage discharge. Gas can be condensed and recovered through the exhaust port or directly treated with exhaust gas, and the extracted solvent can be used as the working fluid for recycling, which is conducive to environmental protection and emission reduction. Especially suitable for processes that contain organic solvents, toxic substances, and require recycling in the extracted medium.
Application scope:
The products are widely used in industries such as machinery, petroleum, chemical, papermaking, electronics, mining, metallurgy, medicine, sugar making, printing and dyeing, plastics, pesticides, brick and tile machinery, low-temperature equipment, food machinery, and other fields. The products are sold to various regions in China and are highly trusted and praised by users.
The main characteristics of closed circuit circulation system of water ring vacuum pump are as follows:
1. The unit is supplied as a complete set of equipment, including gas-liquid separator, heat exchanger, frame, internal pipeline and other accessories, which is more conducive to the installation of users and can greatly shorten the installation cycle of users.
2. The working liquid can be recycled with water or various chemical solvents, which greatly reduces the environmental pollution in the chemical industry.
3. If the extracted medium is used as the working liquid, the extracted medium can be recovered.
4. 2BW series closed-loop system needs to be designed according to the user's inlet condition, cooling water condition, exhaust port condition and so on, which belongs to non-standard product.
Working principle：
2BW series liquid ring vacuum pump closed circuit circulation system is a complete set of equipment composed of 2BV or 2BE series liquid ring vacuum pump, steam water separator, heat exchanger and various pipeline accessories. Compared with a single liquid ring vacuum pump, it is more convenient to install. Because the working fluid can be recycled, the system greatly reduces the consumption of working fluid and the pollution to the environment, so it has obvious advantages in situations where the extracted gas contains toxic, organic solvents, inflammables and explosives.
The working fluid of the liquid ring vacuum pump closed-circuit circulating system can use a variety of media: water, methanol, ethanol, xylene, aniline acetone, and other organic solvents, transformer oil, etc.
Flow chart of closed circuit circulating system (unit) of 2BW liquid ring vacuum pump, one for operation and one for standby
Product Description：
The 2BW water ring vacuum pump closed-loop unit is a vacuum pump unit composed of auxiliary components such as vapor liquid separator, heat exchanger, valve, instrument, and pipeline added to the water ring pump. This unit can allow the working fluid of the water ring vacuum pump to be continuously circulated in the gas-liquid separator and pump chamber, reducing sewage discharge. Gas can be condensed and recovered through the exhaust port or directly treated with exhaust gas, and the extracted solvent can be used as the working fluid for recycling, which is conducive to environmental protection and emission reduction. Especially suitable for processes that contain organic solvents, toxic substances, and require recycling in the extracted medium.
Application scope:
The products are widely used in industries such as machinery, petroleum, chemical, papermaking, electronics, mining, metallurgy, medicine, sugar making, printing and dyeing, plastics, pesticides, brick and tile machinery, low-temperature equipment, food machinery, and other fields. The products are sold to various regions in China and are highly trusted and praised by users.
The main characteristics of closed circuit circulation system of water ring vacuum pump are as follows:
1. The unit is supplied as a complete set of equipment, including gas-liquid separator, heat exchanger, frame, internal pipeline and other accessories, which is more conducive to the installation of users and can greatly shorten the installation cycle of users.
2. The working liquid can be recycled with water or various chemical solvents, which greatly reduces the environmental pollution in the chemical industry.
3. If the extracted medium is used as the working liquid, the extracted medium can be recovered.
4. 2BW series closed-loop system needs to be designed according to the user's inlet condition, cooling water condition, exhaust port condition and so on, which belongs to non-standard product.
Working principle：
2BW series liquid ring vacuum pump closed circuit circulation system is a complete set of equipment composed of 2BV or 2BE series liquid ring vacuum pump, steam water separator, heat exchanger and various pipeline accessories. Compared with a single liquid ring vacuum pump, it is more convenient to install. Because the working fluid can be recycled, the system greatly reduces the consumption of working fluid and the pollution to the environment, so it has obvious advantages in situations where the extracted gas contains toxic, organic solvents, inflammables and explosives.
The working fluid of the liquid ring vacuum pump closed-circuit circulating system can use a variety of media: water, methanol, ethanol, xylene, aniline acetone, and other organic solvents, transformer oil, etc.
Flow chart of closed circuit circulating system (unit) of 2BW liquid ring vacuum pump, one for operation and one for standby
