Overview of 2SK Water Ring Vacuum Pump
The 2SK series water ring vacuum pump and compressor are used to extract or compress air and other non corrosive, insoluble, and solid particle free gases, in order to form vacuum and pressure in a closed container. The inhaled gas allows for a small amount of liquid to be mixed.
Technical parameter：
型号 model | 最大抽气量 Maximum air extraction capacity m3/min | 极限真空度 Ultimate vacuum | 功率 power kw | 转速 speed r/min | 供水量 Water supply L/min | 泵总重 Total weight of pump kg | 推荐替代产品 Recommended alternatives |
2SK-1.5 | 1.5 | -735mmHg (-0.098MPa) | 4 | 1440 | 10-15 | 200 | 2BV5 110 |
2SK-3 | 3 | 7.5 | 1440 | 15-20 | 310 | 2BV5 111 | |
2SK-6 | 6 | 15 | 1440 | 25-35 | 460 | 2BV5 131 | |
2SK-12 | 12 | 22 | 970 | 40-50 | 730 | 2BE1 202 | |
2SK-20 | 20 | 45 | 740 | 60-80 | 1650 | 2BE1 252 | |
2SK-30 | 30 | 55 | 740 | 70-90 | 2300 | 2BE1 253 |
Main features：
1 、Compared with SK series single-stage water ring vacuum pump, it has the characteristics of high vacuum degree and high pumping speed in high vacuum area.
2、At the same pumping rate, the shaft power is higher than 2BV and 2BE1 series.
3、As the structure is of double impeller structure, the manufacturing and maintenance are relatively complicated, and there are many vulnerable parts.
Factory Shooting
Source factory, quality assurance, support for customization
